MODEL HBS-62.5 DIGITAL DISPLAY LOW
LOAD BRINELL HARDNESS TESTER
. The Graphical User Interface is adopted and the operating
system can be changed between Chinese and English. The
system adopts quick and convenient menu operation.
. The parameters of every measurement can be autosaved and
the testing procedure can be performed automatically.
. The testing data can be processed automatically and the
hardness value's converting can also be performed auto-
. An advanced frictionless loading shaft mechanism is
adopted. It can ensure the accurate and reliable test.
Measuring range: 4-450HBS, 4-650HBW
Test force: 9.807，49.03，98.07，153.2，294.2，612.9N
(1, 5, 10, 15.625, 30, 62.5kgf)
Max. height of test piece: 180mm
Depth of throat: 125mm
Magnifications of the optical micrometer: 125X, 50X
Min. scale value of the optical micrometer: 1μm, 2.5μm
Power supply: 220V AC or 110V AC, 50/60Hz
Dimensions: 580 x 260 x 730mm
Weight: Approx. 90kg
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Steel ball penetrator: Φ1, Φ2, Φ2.5mm, 1 pc. each
Brinell standardized block: 3 pcs.
