Suitable for use in the laboratory, as well as for use in harsh industrial environments, e.g.

FD8612APS
Pressure Sensors for Wall Mounting Type

● HEVAC applications, clean room technology, medical technology, filter technology and finishing pass technology.
● The robust mechanics guarantees long term stability, linearity and good reproducibility.
● Temperature drift reduced to a minimum by specific compensation of the sensors.
● Operation is almost maintenance-free, as a result
of the freefrom-wear inducSuitable for use in the laboratory, as well as for use in harsh industrial environments, e.g.tive measuring system.
● As standard, the integrated electronics provide a pressure proportional voltage signal from 0 to 2V as output.

Options:

OD8612L2	Linearity 0.2% with DPS only in ranges ≥ 2.5 mbar with APS only in range ≤ 100 mbar
OD8612L5	Linearity 0.5% with DPS only in ranges ≥ 1 mbar with APS only in range ≤ 200 mbar
OD8612N	Power supply : 230 V
OD8612R2	Output 0 to 10 V (voltage supply 19 to 31 V DC)
OD8612R3	Output 0 / 4 to 20 mA (voltage supply 19 to 31 V DC)

Accessories:

ZA8612AK2	Connecting cable 2m long mounted with connector for connection to ALMEMO® devices
ZB2295S	1 set silicone hoses 2m long black/colourless
ZB2295SSL	Silicone hose black per m
ZB2295SFL	Silicone hose colourless per m

Technical Data:
Linearity:	±1% of final value, option: ±0.2% or ±0.5%
Hysteresis:	±0.1% of final value
Nominal temperature:	23°C
Overload capacity:	up to 400 mb: 5-fold, from 500 mb: 2-fold
Max. common mode pressure:	1 bar (at differential measurement)
Power supply:	6VDC, option: 230V 50/60Hz
Power consumption:	approx. 3.5mA
Output:	0 to 2V, option: 0 to 10V/0(4) to 20mA
Connection:	electrical: screw terminals, screwed cable gland PG 7, pressure: 6.5mm hose connection
Rise time:	T90 approx. 0.02s
Temperature drift: Zero point range	0.03% of final value / K, 0.03% of final value / K
Operative range:	+10 to +50°C , air humidity 10 to 90% non-condensing
Storage temperature:	-10 to +70°C
Housing:	material ABS 120 x 80 x 55mm (L x H x D)
Safety class:	0
Protection system:	IP 54
Weight:	approx. 300g
Sensor capacity:	approx. 3ml
Volume increase:	approx. 0.2ml at nom. press.

Types:
Measuring ranges absolute pressure:
FD8612APS	0 to 1000 mbar, 900 to 1100 mbar, 800 to 1200 mbar Pressure transducer type APS Please specify measuring range
