● Wire strain gauges
in four-conductor full-bridge circuit.
● Control resistance
for final adjustment of the measuring
range.
● All measuring
ranges that are specified in Newton can also be supplied in kg ranges.
Options for all Force Transducers:
| OK9000K |
Indication of measured values with
ALMEMO® devices in kg |
| OK9000NK |
Indication of measured values with
ALMEMO® devices in N and kg |
Accessories:
| ZB902512 |
Knuckle eyes with
external thread M 12 (2 pcs)
(dimensions in mm: D = M 12, E = 16,
F = 32, G = 12, L = 54) |
| ZB902524 |
Knuckle eyes with
external thread M 24 x 2 (2 pcs)
(dimensions in mm: D = M 24 x 2, E = 26,
F = 62, G = 25, L = 94) |
|
| Technical Data: |
| Max. load limit: |
150% of final value |
| Maximum dynamic load: |
70% of final value |
| Reference temperature: |
23°C |
| Cable: |
3m long, with axial
ALMEMO® connector |
| Accuracy for tension: |
<±0.1% of fin. val. |
| Accuracy for tension and compression:
<±0.2% of fin. val. |
| Nominal measuring path: |
<0.15mm |
| Operative range: |
-10 to +70°C |
| Drift error at permanent load: |
<0.07% per 30min |
| Permissible lateral forces: |
±60% of fin. val. |
| Protection system: |
up to 1kN: IP 65,
from 2kN: IP 67 |
| Material: |
up to 1kN: aluminium
2 to 50kN: stainless |
| Dimensions in mm |
up to 10kN:
A=50, B=75, C=20, D=M12
20kN, 50kN:
A=65, B=85,
C=40, D=M24 x2 |
| Types: |
| FKA0251 |
Measuring range 0.02kN 0.05kN, 0.1kN,
0.2kN, 0.5kN, 1kN, 2kN, 5kN or 10kN
please specify |
| FKA0252 |
Measuring range 20kN |
| FKA0255 |
Measuring range 50kN |
▒ All
ALMEMO® devices provide easy push-button
adjustment of no-load and final value.
|
